Bare earth elevation surface (DTM) and actual surface (DSM) given in meters in the NAVD88 (Geoid12A realization) vertical reference frame. Horizontal coordinates referenced to appropriate UTM zone. Bare earth is created by classifying and removing vegetation and man-made structures from lidar point cloud prior to surface generation. Both the DSM and DTM are mosaicked onto a spatially uniform grid at 1 m spatial resolution in 1 km by 1 km tiles provided in a geotiff format.

The LIDAR Composite DTM (Digital Terrain Model) is a raster elevation model covering ~99% of England at 1m spatial resolution. The DTM (Digital Terrain Model) is produced from the last or only laser pulse returned to the sensor. We remove surface objects from the Digital Surface Model (DSM), using bespoke algorithms and manual editing of the data, to produce a terrain model of just the surface.

Produced by the Environment Agency in 2022, the DTM is derived from a combination of our Time Stamped archive and National LIDAR Programme surveys, which have been merged and re-sampled to give the best possible coverage. Where repeat surveys have been undertaken the newest, best resolution data is used. Where data was resampled a bilinear interpolation was used before being merged.

The 2022 LIDAR Composite contains surveys undertaken between 6th June 2000 and 2nd April 2022. Please refer to the metadata index catalgoues which show for any location which survey was used in the production of the LIDAR composite.

The data is available to download as GeoTiff rasters in 5km tiles aligned to the OS National grid. The data is presented in metres, referenced to Ordinance Survey Newlyn and using the OSTN’15 transformation method. All individual LIDAR surveys going into the production of the composite had a vertical accuracy of +/-15cm RMSE.

The Dauphin County, PA 2016 QL2 LiDAR project called for the planning, acquisition, processing and derivative products of LIDAR data to be collected at a nominal pulse spacing (NPS) of 0.7 meters. Project specifications are based on the U.S. Geological Survey National Geospatial Program Base LIDAR Specification, Version 1.2. The data was developed based on a horizontal projection/datum of NAD83 (2011) State Plane Pennsylvania South Zone, US survey feet; NAVD1988 (Geoid 12B), US survey feet. LiDAR data was delivered in RAW flight line swath format, processed to create Classified LAS 1.4 Files formatted to 711 individual 5,000-foot x 5,000-foot tiles. Tile names use the following naming schema: "YYYYXXXXPAd" where YYYY is the first 3 characters of the tile's upper left corner Y-coordinate, XXXX - the first 4 characters of the tile's upper left corner X-coordinate, PA = Pennsylvania, and d = 'N' for North or 'S' for South. Corresponding 2.5-foot gridded hydro-flattened bare earth raster tiled DEM files and intensity image files were created using the same 5,000-foot x 5,000-foot schema. Hydro-flattened breaklines were produced in Esri file geodatabase format. Continuous 2-foot contours were produced in Esri file geodatabase format. Ground Conditions: LiDAR collection began in Spring 2016, while no snow was on the ground and rivers were at or below normal levels. In order to post process the LiDAR data to meet task order specifications, Quantum Spatial established a total of 84 control points (24 calibration control points and 60 QC checkpoints). These were used to calibrate the LIDAR to known ground locations established throughout the project area.

The 10 m resolution Lidar Digital Elevation Model (DEM) is the primary elevation data product produced and distributed by the National Park Service, Great Smoky Mountains National Park.

The lidar Digital Elevation Model (DEM) is the primary elevation data product produced and distributed by the National Park Service, Great Smoky Mountains National Park.

The High Resolution Digital Elevation Model (HRDEM) product is derived from airborne LiDAR data (mainly in the south) and satellite images in the north. The complete coverage of the Canadian territory is gradually being established. It includes a Digital Terrain Model (DTM), a Digital Surface Model (DSM) and other derived data. For DTM datasets, derived data available are slope, aspect, shaded relief, color relief and color shaded relief maps and for DSM datasets, derived data available are shaded relief, color relief and color shaded relief maps. The productive forest line is used to separate the northern and the southern parts of the country. This line is approximate and may change based on requirements. In the southern part of the country (south of the productive forest line), DTM and DSM datasets are generated from airborne LiDAR data. They are offered at a 1 m or 2 m resolution and projected to the UTM NAD83 (CSRS) coordinate system and the corresponding zones. The datasets at a 1 m resolution cover an area of 10 km x 10 km while datasets at a 2 m resolution cover an area of 20 km by 20 km. In the northern part of the country (north of the productive forest line), due to the low density of vegetation and infrastructure, only DSM datasets are generally generated. Most of these datasets have optical digital images as their source data. They are generated at a 2 m resolution using the Polar Stereographic North coordinate system referenced to WGS84 horizontal datum or UTM NAD83 (CSRS) coordinate system. Each dataset covers an area of 50 km by 50 km. For some locations in the north, DSM and DTM datasets can also be generated from airborne LiDAR data. In this case, these products will be generated with the same specifications as those generated from airborne LiDAR in the southern part of the country. The HRDEM product is referenced to the Canadian Geodetic Vertical Datum of 2013 (CGVD2013), which is now the reference standard for heights across Canada. Source data for HRDEM datasets is acquired through multiple projects with different partners. Since data is being acquired by project, there is no integration or edgematching done between projects. The tiles are aligned within each project. The product High Resolution Digital Elevation Model (HRDEM) is part of the CanElevation Series created in support to the National Elevation Data Strategy implemented by NRCan. Collaboration is a key factor to the success of the National Elevation Data Strategy. Refer to the “Supporting Document” section to access the list of the different partners including links to their respective data.

The Digital Elevation Model Imagery Catalog layer describes precision elevation datasets acquired from LiDAR and aerial / satellite sensors currently archived in the department. Precision elevation products are defined as Digital Terrain Models (or bare Earth Digital Elevation Models) captured from either LiDAR sources or photogrammetrically derived from aerial photography. LiDAR classified point clouds and derived Digital Terrain Models under a CC-BY license have been uploaded to the ELVIS Elevation and Depth Online Portal (https://elevation.fsdf.org.au/).

This is a tiled collection of the 3D Elevation Program (3DEP) and is one meter resolution. The 3DEP data holdings serve as the elevation layer of The National Map, and provide foundational elevation information for earth science studies and mapping applications in the United States. Scientists and resource managers use 3DEP data for hydrologic modeling, resource monitoring, mapping and visualization, and many other applications. The elevations in this DEM represent the topographic bare-earth surface. USGS standard one-meter DEMs are produced exclusively from high resolution light detection and ranging (lidar) source data of one-meter or higher resolution. One-meter DEM surfaces are seamless within collection projects, but, not necessarily seamless across projects. The spatial reference used for tiles of the one-meter DEM within the conterminous United States (CONUS) is Universal Transverse Mercator (UTM) in units of meters, and in conformance with the North American Datum of 1983 ...

The Digital Elevation Model (DEM) 25 Metre Grid of Australia derived from LiDAR model represents a National 25 metre (bare earth) DEM which has been derived from some 236 individual LiDAR surveys between 2001 and 2015 covering an area in excess of 245,000 square kilometres. These surveys cover Australia's populated coastal zone; floodplain surveys within the Murray Darling Basin, and individual surveys of major and minor population centres. All available 1 metre resolution LiDAR-derived DEMs have been compiled and resampled to 25 metre resolution datasets for each survey area, and then merged into a single dataset for each State. These State datasets have also been merged into a 1 second resolution national dataset.

This resource contains Lidar-DEM collection status shapefiles from the Texas Natural Resources Information System (TNRIS) [http://tnris.org]. November 2023 updates: this year, TNRIS changed its name to Texas Geographic Information Office (TxGIO). The domain name hasn't changed yet, but the data hub is continually evolving. See [1], [2] for current downloadable data.

For purposes of Hurricane Harvey studies, the 1-m DEM for Harris County (2008) has also been uploaded here as a set of 4 zipfiles containing the DEM in tiff files. See [1] for a link to the current elevation status map and downloadable DEMs.
Project name: H-GAC 2008 1m Datasets: 1m Point Cloud, 1M Hydro-Enforced DEM, 3D Breaklines, 1ft and 5ft Contours Points per sq meter: 1 Total area: 3678.56 sq miles Source: Houston-Galveston Area Council (H-GAC) Acquired by: Merrick, QA/QC: Merrick Catalog: houston-galveston-area-council-h-gac-2008-lidar

References: [1] TNRIS/TxGIO StratMap elevation data [https://tnris.org/stratmap/elevation-lidar/] [2] TNRIS/TxGIO DataHub [https://data.tnris.org/]

This raster dataset contains LiDAR-derived elevation data flown from Fall 2015 to Spring 2016, with additional reflights through Fall 2016. This dataset encompasses all of the LARIAC4 project, comprised of approximately 4214 square miles.

The NOAA Office for Coastal Management (OCM) downloaded this digital elevation model (DEM) data from the USGS site: ftp://rockyftp.cr.usgs.gov/vdelivery/Data...

This lidar data set includes unclassified swath LAS 1.4 files, classified LAS 1.4 files, breaklines, digital elevation models (DEMs), first return digital surface models (DSMs), and intensity imagery. Geographic Extent: Fourteen partial counties in Utah, covering approximately 7,005 total square kilometers; partial coverage of three counties covering approximately 182 square kilometers in the Minidoka QL1 AOI. This area is part of the Bear Lake / Cache Valley QL1 AOI. Dataset Description: The Utah 2016 Lidar project called for the planning, acquisition, processing, and derivative products of lidar data to be collected at a nominal pulse spacing (NPS) of 0.35 meters. Project specifications are based on the U.S. Geological Survey National Geospatial Program Base Lidar Specification, Version 1.2. The data was developed based on a horizontal projection/datum of NAD83 (2011), UTM Zone 12, meters and vertical datum of NAVD88 (GEOID12B), meters. Lidar data was delivered as flightline-extent unclassified LAS swaths, as processed Classified LAS 1.4 files formatted to 215 individual 1,000 meter x 1,000 meter tiles; as tiled intensity imagery, as tiled bare earth DEMs, and as tiled first return DSMs all tiled a 2,000 meter x 2,000 meter schema (82 tiles). Continuous breaklines were produced in Esri shapefile format. Ground Conditions: Lidar was partially collected in fall of 2016, while no snow was on the ground and rivers were at or below normal levels. In order to post process the lidar data to meet task order specifications and meet ASPRS vertical accuracy guidelines, Quantum Spatial, Inc. established a total of 28 ground control points that were used to calibrate the lidar to known ground locations established throughout the project area. An additional 5 independent accuracy checkpoints, 5 in Bare Earth and Urban landcovers (5 NVA points), 6 in the Shrubs and Tall Grass category (6 VVA points), were used to assess the vertical accuracy of the data. These checkpoints were not used to calibrate or post process the data.

A first-surface topography Digital Elevation Model (DEM) mosaic for the Little Pine Island Bayou Corridor Unit of Big Thicket National Preserve in Texas was produced from remotely sensed, geographically referenced elevation measurements collected on January 15, 21, 22, 26, and 30, 2014 by the U.S. Geological Survey, in cooperation with the National Park Service - Gulf Coast Network. Elevation measurements were collected over the area using the second-generation Experimental Advanced Airborne Research Lidar (EAARL-B), a pulsed laser ranging system mounted onboard an aircraft to measure ground elevation, vegetation canopy, and coastal topography. The system uses high-frequency laser beams directed at the Earth's surface through an opening in the bottom of the aircraft's fuselage. The laser system records the time difference between emission of the laser beam and the reception of the reflected laser signal in the aircraft. The plane travels over the target area at approximately 55 meters per second at an elevation of approximately 300 meters, resulting in a laser swath of approximately 240 meters with an average point density of 1.4 points per square meter. A peak sampling rate of 15-30 kilohertz results in an extremely dense spatial elevation dataset. More than 100 kilometers of coastline can be surveyed easily within a 3- to 4-hour mission. When resultant elevation maps for an area are analyzed, they provide a useful tool to make management decisions regarding land development.

These digital elevation models (DEMs) were generated from light detection and ranging (lidar) point clouds (LPCs) derived from lidar data collected during multiple field campaigns at three study areas near Winter Park, Colorado. Small, uncrewed aircraft systems (sUAS) were used to collect lidar datasets to represent snow-covered and snow-free periods.

This statewide product was created and will continue to be maintained by the Eastern Shore Regional GIS Cooperative (ESRGC). It's a comprehensive mosaic of the most current LiDAR available for the State of Maryland.The creation and maintenance of this dataset, along with the creation of its services, was funded by the Maryland Department of Information Technology.This is a MD iMAP hosted service. Find more information at https://imap.maryland.gov.Image Service Link: https://lidar.geodata.md.gov/imap/rest/services/Statewide/MD_statewide_dem_ft/ImageServer

This dataset contains a seamless high resolution, two-meter, topographic lidar digital elevation model (DEM) of the Lower Texas Coast. The elevations in this DEM represent the topographic bare-earth surface. The dataset is a fusion of several airborne topographic light detection and ranging (lidar) surveys acquired by various surveyors between the years 2007 – 2019 where coverage is primarily from 2018 and 2019. The landward extent of the lidar surveys selected for the creation of this DEM is determined by the boundary of the ADvanced CIRCulation (ADCIRC) TX2008_R35H computational mesh obtained from the Computational Hydraulics Group at The University of Texas at Austin. The spatial reference used for the tiles in the DEM is in Universal Transverse Mercator (UTM) Zone 14 in units of meters and in conformance with the North American Datum of 1983 (NAD83). All bare earth elevations are referenced to the North American Datum of 1988 (NAVD88). The 2-meter DEM of the upper Texas coast is available under GRIIDC Unique Dataset Identifier (UDI): HI.x833.000:0009 (DOI: 10.7266/2MYPTJ7Y).

This data release consists of three child items distinguishing the following types of data: light detection and ranging (lidar) point clouds (LPCs), digital elevation models (DEMs), and snow depth raster maps. These three data types are all derived from lidar data collected on small, uncrewed aircraft systems (sUAS) at study areas in the Upper Colorado River Basin, Colorado, from 2020 to 2022. These data were collected and generated as part of the U.S. Geological Survey's (USGS) Next Generation Water Observing Systems (NGWOS) Upper Colorado River Basin project.

Zoom in on the map above and click your area of interest or use the Tile Index linked below to determine which package(s) you require for download. The DTM data is available in the form of 1-km by 1-km non-overlapping tiles grouped into packages for download.This dataset is a compilation of lidar data from multiple acquisition projects, as such specifications, parameters and sensors may vary by project. See the detailed User Guide linked below for additional information.

You can monitor the availability and status of lidar projects on the Ontario Lidar Coverage map on the Ontario Elevation Mapping Program hub page.

Now also available through a web service which exposes the data for visualization, geoprocessing and limited download. The service is best accessed through the ArcGIS REST API, either directly or by setting up an ArcGIS server connection using the REST endpoint URL. The service draws using the Web Mercator projection.

For more information on what functionality is available and how to work with the service, read the Ontario Web Raster Services User Guide. If you have questions about how to use the service, email Geospatial Ontario (GEO) at geospatial@ontario.ca.

Service Endpoints

https://ws.geoservices.lrc.gov.on.ca/arcgis5/rest/services/Elevation/Ontario_DTM_LidarDerived/ImageServer https://intra.ws.geoservices.lrc.gov.on.ca/arcgis5/rest/services/Elevation/Ontario_DTM_LidarDerived/ImageServer (Government of Ontario Internal Users)

Additional Documentation

Ontario DTM (Lidar-Derived) - User Guide (DOCX)

OMAFRA Lidar 2016-2018 -Cochrane-Additional Contractor Metadata (PDF) OMAFRA Lidar 2016-2018 -Peterborough-AdditionalContractorMetadata (PDF) OMAFRA Lidar 2016-2018 -Lake Erie-AdditionalContractorMetadata (PDF) CLOCA Lidar 2018 - Additional Contractor Metadata (PDF) South Nation Lidar 2018-19 - Additional Contractor Metadata (PDF) OMAFRA Lidar 2022 - Lake Huron - Additional Contractor Metadata (PDF) OMAFRA Lidar 2022 - Lake Simcoe - Additional Contractor Metadata (PDF) Huron-Georgian Lidar 2022-23 - Additional Contractor Metadata (Word) Kawartha Lakes Lidar 2023 - Additional Contractor Metadata (Word) Sault Ste Marie Lidar 2023-24 - Additional Contractor Metadata (Word) Thunder Bay Lidar 2023-24 - Additional Contractor Metadata (Word) Timmins Lidar 2024 - Additional Contractor Metadata (Word)

Ontario DTM (Lidar-Derived) - Tile Index (SHP) Ontario Lidar Project Extents (SHP)

OMAFRA Lidar DTM 2016-2018 -Cochrane- Breaklines (SHP) OMAFRA Lidar DTM 2016-2018 -Peterborough-Breaklines (SHP) OMAFRA Lidar DTM 2016-2018 -Lake Erie-Breaklines (SHP) CLOCA Lidar DTM 2018-Breaklines (SHP) South Nation Lidar DTM 2018-19-Breaklines (SHP) Ottawa-Gatineau Lidar DTM 2019-20 - Breaklines (SHP) OMAFRA Lidar DTM 2022 - Lake Huron - Breaklines (SHP) OMAFRA Lidar DTM 2022 - Lake Simcoe - Breaklines (SHP) Eastern Ontario Lidar DTM 2021-22 - Breaklines (SHP) Muskoka Lidar DTM 2018 - Breaklines CGVD2013 (SHP) / CGVD28 (SHP) Muskoka Lidar DTM 2021 - Breaklines CGVD2013 (SHP) / CGVD28 (SHP) Muskoka Lidar DTM 2023 - Breaklines CGVD2013 (SHP) / CGVD28 (SHP) DEDSFM Huron-Georgian Bay 2022-23 - Breaklines (SHP) DEDSFM Kawartha Lakes 2023 - Breaklines (SHP) DEDSFM Sault Ste Marie 2023-24- UTM16 - Breaklines (SHP) DEDSFM Sault Ste Marie 2023-24- UTM17 - Breaklines (SHP) DEDSFM Sudbury 2023-24 - Breaklines (SHP) DEDSFM Thunder Bay 2023-24 - Breaklines (SHP) DEDSFM Timmins 2024 - Breaklines (SHP)

Product PackagesDownload links for the Ontario DTM (Lidar-Derived) (Word) Projects: LEAP 2009 GTA 2014-18 OMAFRA 2016-18 CLOCA 2018 South Nation CA 2018-19 Muskoka 2018-23 York-Lake Simcoe 2019 Ottawa River 2019-20 Ottawa-Gatineau 2019-20 Lake Nipissing 2020 Hamilton-Niagara 2021 Huron Shores 2021 Eastern Ontario 2021-22 OMAFRA Lake Huron 2022 OMAFRA Lake Simcoe 2022 Belleville 2022 Digital Elevation Data to Support Flood Mapping 2022-26

Huron-Georgian Bay 2022-23 Kawartha Lakes 2023 Sault Ste Marie 2023-24 Sudbury 2023-24 Thunder Bay 2023-24 Timmins 2024

Greater Toronto Area Lidar 2023

Status On going: Data is continually being updated

Maintenance and Update Frequency As needed: Data is updated as deemed necessary

Contact Ontario Ministry of Natural Resources - Geospatial Ontario,geospatial@ontario.ca

LiDAR Derived Digital Elevation Models available at a 1m resolution in New Brunswick Stereographic Double Projection (NBSDP). LiDAR Derived Digital Elevation Models and Digital Surface Models available at 1m or 2m resolutions from NRCAN in Universal Transverse Mercator (UTM).

Peel's Digital Elevation Model (DEM) provides a generalized representation of both surface and ground features at a 1 metre resolution. The data is created using breaklines and a 10-metre grid of masspoints, both of which are photogrammatically created.

Available products

Peel Digital Elevation Model in TIFF format - 1.5 Gigabytes

Specifications

Capture year: Spring 2022 Spatial resolution: 1-metre File format: GeoTIFF, losslessly compressed Pixel type and depth: 32-bit float Horizontal projection: NAD 1983 UTM Zone 17N (EPSG: 26917) Vertical projection: CGVD 1928 (EPSG: 5713) Horizontal accuracy: ±50 centimetres Vertical accuracy: ±50 centimetres Method of creation: photogrammetric

Other data (Lidar) The Region of Peel doesn't have Lidar data in-house. The Province of Ontario through Land Information Ontario provides the following Lidar and Lidar-based datasets through their open data program:

Lidar-derived Digital Terrain Model (DTM) Lidar-derived Digital Surface Model (DSM) Lidar-derived classified point cloud - by request
